Circulaire® Recirculating Fume Cupboard is designed to safely contain and filter hazardous fumes, vapours, and airborne particulates in laboratories and industrial environments.
Circulaire® Pro Recirculating Fume Cupboard
with Visionaire® Touchscreen Interface.
Product Description.
Recirculating Fume Cupboards can be installed anywhere within your workspace and, thanks to our advanced carbon filtration technology, require no ducting to an external environment. This system utilises high-efficiency filters to provide optimal protection for users without the need for external ventilation. Its compact design makes it ideal for spaces with limited access to an external exhaust, offering a reliable and energy-efficient alternative to traditional fume hoods. We offer Activated Carbon, for Chemical Filtration or HEPA Filters, for Particulate, or a combination if your application requires.
- Enhanced Safety: Designed to protect users from inhaling harmful fumes, the recirculating system ensures that hazardous substances are contained and filtered efficiently.
- Energy Efficiency: The closed-loop system eliminates the need for external ducting, reducing energy costs associated with traditional fume cupboards.
- Space-Saving Design: Ideal for laboratories or spaces without access to external exhaust systems, the compact design makes installation easier and more versatile.
- Cost-Effective: With no need for costly ductwork, installation and maintenance costs are significantly reduced.
The Recirculating Fume Cupboard operates by drawing air into the unit through the front sash.
As air passes through the system, it is filtered by high-performance particulate and activated carbon filters, which trap harmful chemicals, fumes, and particulates. Clean, filtered air is then recirculated back into the workspace.
The unit is equipped with variable airflow control to ensure that the flow rate is optimised for the specific needs of the user. Additionally, real-time data on airflow and filter performance is available through the digital interface, ensuring that the system continues to operate safely and efficiently.
Recirculating clean air back into your laboratory or working environment ensures that Ductless Fume Hood solutions are more environmentally friendly than a Ducted option, and the environmental impact of exhausting fumes to the outside atmosphere.
- Base Stand | with Lockable Castors | with Vented Under Cupboard
- Spillage Tray | Polypropylene | 316 Stainless Steel
- Rear Stainless Steel Scaffolding System
- Services | Water | Gas
- Cable Entry Points
- Double Electrical Sockets
- Enclosure | Stainless Steel | Polypropylene | PVC
Recirculating Fume Cupboards can be installed anywhere within your workspace and, thanks to our advanced carbon filtration technology, require no ducting to an external environment.
This system utilises high-efficiency filters to provide optimal protection for users without the need for external ventilation. Its compact design makes it ideal for spaces with limited access to an external exhaust, offering a reliable and energy-efficient alternative to traditional fume hoods. We offer Activated Carbon, for Chemical Filtration or HEPA Filters, for Particulate, or a combination if your application requires.
- Enhanced Safety: Designed to protect users from inhaling harmful fumes, the recirculating system ensures that hazardous substances are contained and filtered efficiently.
- Energy Efficiency: The closed-loop system eliminates the need for external ducting, reducing energy costs associated with traditional fume cupboards.
- Space-Saving Design: Ideal for laboratories or spaces without access to external exhaust systems, the compact design makes installation easier and more versatile.
- Cost-Effective: With no need for costly ductwork, installation and maintenance costs are significantly reduced.
The Recirculating Fume Cupboard operates by drawing air into the unit through the front sash.
As air passes through the system, it is filtered by high-performance particulate and activated carbon filters, which trap harmful chemicals, fumes, and particulates. Clean, filtered air is then recirculated back into the workspace.
The unit is equipped with variable airflow control to ensure that the flow rate is optimised for the specific needs of the user. Additionally, real-time data on airflow and filter performance is available through the digital interface, ensuring that the system continues to operate safely and efficiently.
Recirculating clean air back into your laboratory or working environment ensures that Ductless Fume Hood solutions are more environmentally friendly than a Ducted option, and the environmental impact of exhausting fumes to the outside atmosphere.
- Base Stand | with Lockable Castors | with Vented Under Cupboard
- Spillage Tray | Polypropylene | 316 Stainless Steel
- Rear Stainless Steel Scaffolding System
- Services | Water | Gas
- Cable Entry Points
- Double Electrical Sockets
- Enclosure | Stainless Steel | Polypropylene | PVC
Technical Specification.
- Circulaire® Touchscreen | CT
- Circulaire® Touchscreen Pro | CTP
- Filter Specification
- Videos
- Documents
| Model | CT 800 | CT1100 | CT1400 | CT1800 |
|---|---|---|---|---|
| External Dims (WxHxD) | 800mm x 1285mm x 700mm* | 1100mm x 1285mm x 700mm* | 1400mm x 1285mm x 700mm* | 1800mm x 1285mm x 700mm* |
| Aperture (WxH) | 500mm x 274mm | 800mm x 274mm | 1100mm x 274mm | 1500mm x 274mm |
| Power | 61W | 161W | 161W | 276W |
| Weight | 91kg | 132kg | 140kg | 200kg |
| Filters | Large Capacity CARBON or HEPA + Optional Outlet Filter | |||
| Sound | <53dB | <61dB | <59dB | <55dB |
| Model | CTPro 800 | CTPro 1100 | CTPro 1400 | CTPro 1800 |
|---|---|---|---|---|
| External Dims (WxHxD) | 800mm x 1275mm** x 700mm*** | 1100mm x 1275mm** x 700mm** | 1400mm x 1275mm** x 700mm** | 1800mm x 1275mm** x 700mm** |
| Aperture (WxH) | 670mm x 280mm (Working)/500mm (Max) | 970mm x 280mm (Working)/500mm (Max) | 1270mm x 280mm (Working)/500mm (Max) | 1570mm x 280mm (Working)/500mm (Max) |
| Sash | Sliding | |||
| Power | 57W | 207W | 207W | 322W |
| Weight | 104kg | 141kg | 167kg | 184kg |
| Filters | Large Capacity CARBON or HEPA + Optional Outlet Filter | |||
| Sound | <53dB | <61dB | <59dB | <55dB |
| Suitable for Removal of | |
|---|---|
| AC | General Organic Compounds [iodine, Solvents, Odours etc] |
| ACID | Acidic Compounds [and general organics] |
| ACR | Alkali Compounds [and general organics] |
| AMM | Ammonia & amine compounds [and general organics] |
| CYN | Cyanide Compounds |
| ETHER | Ether Compounds [and general organics] |
| FORM | Aldehydes [and general organics] |
| SUL | Sulphur Compounds [and general organics] |
| MCH | Special blend of up to 4 of the above carbon types |
| ED | Tri-Layered Filter for schools [organic, acid & alkali removed] |
Features & Benefits.
Recirculating Technology
Eliminates expensive external ducting, simplifies installation, and makes the unit portable for flexible positioning.
Touchscreen Control Interface
Real-time monitoring of airflow and filter life enhances user safety and reduces downtime.
Energy Efficient
Recirculating air reduces the need for external ventilation, lowering energy consumption and operational costs.
Activated Carbon Filteration
Captures a wide range of chemicals and particulates, ensuring a cleaner and safer working environment.
BS 7989 : 2001
Fully compliant for Filtration Fume/Particulate Cupboards and COSHH regulations.
Eco Mode
PIR Sensors ensure efficient energy consumption by placing the cabinet in Eco Mode after a period of operator inactivity.
