The Ductaire Ducted Fume Cupboard offers robust, single-wall steel construction and advanced airflow control to deliver safe and efficient fume extraction.
Designed with a spacious internal working area and intuitive user interface, it ensures operator protection and ease of use.
The Ductaire Pro Ducted Fume Cupboard is engineered to provide protection, ensuring a safe working environment in research facilities, higher education labs, and industrial settings.
With precision airflow control and superior construction quality, our ducted fume cabinet is designed to handle hazardous chemical vapours while safeguarding both your personnel and environment.
Constructed from epoxy-coated mild steel, these aerodynamic industrial fume cupboards deliver exceptional airflow characteristics. They are available in a range of standard and custom sizes to accommodate various laboratory configurations.
In SDI Group Partnership with Safelab Systems
An Air Bypass / Constant Air Volume [CAV] system guarantees full operator protection against hazardous substances. Negative pressure, sustained by a remote exhaust fan, ensures a constant, safe inflow of air inside the working chamber.
CAV | Constant Airflow Volume
Designed using the traditional bypass system which incorporates openings above the sash, a constant air volume fume cupboard (CAV) provides a constant flow of air, whether the cupboard is in use or if the sash is open or closed. The face velocity will stay constant but the exhaust rate and therefore energy usage stays constant.
The Ductaire Pro Ducted Fume Cupboard is engineered to provide protection, ensuring a safe working environment in research facilities, higher education labs, and industrial settings.
With precision airflow control and superior construction quality, our ducted fume cabinet is designed to handle hazardous chemical vapours while safeguarding both your personnel and environment.
Constructed from epoxy-coated mild steel, these aerodynamic industrial fume cupboards deliver exceptional airflow characteristics. They are available in a range of standard and custom sizes to accommodate various laboratory configurations.
In SDI Group Partnership with Safelab Systems
An Air Bypass / Constant Air Volume [CAV] system guarantees full operator protection against hazardous substances. Negative pressure, sustained by a remote exhaust fan, ensures a constant, safe inflow of air inside the working chamber.
CAV | Constant Airflow Volume
Designed using the traditional bypass system which incorporates openings above the sash, a constant air volume fume cupboard (CAV) provides a constant flow of air, whether the cupboard is in use or if the sash is open or closed. The face velocity will stay constant but the exhaust rate and therefore energy usage stays constant.
| Model | D 1000 | D 1200 | D 1500 | D 1800 |
|---|---|---|---|---|
| External Dims (WxHxD) | 1000mm x 2200mm x 770mm | 1200mm x 2200mm x 770mm | 1500mm x 2200mm x 770mm | 1800mm x 2200mm x 770mm |
| Internal Dims (HxD) | 1030mm x 550mm | |||
| Working Aperture | Max. 400mm | Min. 200mm | |||
| PVC Duct Spigot | 250mm | |||
| Air Volume @ 0.5m/s | 610m3/hr | 750m3/hr | 965m3/hr | 1180m3/hr |
Constructed from welded Epoxy Coated Steel or Polypropylene, the cabinet resists corrosion and damage from a wide range of chemicals.
CAV (Constant Air Volume) system control airflow to maintain safety and energy efficiency.
Fully tested and approved to BS EN 14175, the unit meets safety and performance standards.
Motorised sashes, PIR sensor operation, and safety controls work to maintain optimal airflow and protect users from hazardous fumes.
Real-time monitoring of airflow and filter life enhances user safety and reduces downtime.
Available in various sizes and configurations, including walk-in options, the unit can fit specific laboratory requirements.
